Kyocera ECOSYS FS-1135MFP User Manual

3
3-23
Basic Operation
For send to folder (SMB)
For send to folder (FTP)
13 Press [Yes] (the Left Select key). This makes a
connection with the entered destination.
Item Data to be entered
Max.
characters
Host Name
(SMB)*
Host name or IP address of the PC to
receive the data.
Up to 64
characters
Path Path to the receiving folder such as
follows.
For example, User\Sharename.
Up to 128
characters
Login User
Name
User name to access the PC
For example, abcdnet\james.smith
Up to 64
characters
Login
Password
Password to access the PC Up to 64
characters
* To specify a port number different from the default (139), enter using
the format “host name: port number” (e.g., SMBhostname: 140).
Item Data to be entered
Max.
characters
Host Name
(FTP)*
Host name or IP address of FTP server Up to 64
characters
Path Path to the receiving folder.
For example, User\ScanData.
Otherwise the data will be saved in the
home directory.
Up to 128
characters
Login User
Name
FTP server log-in user name Up to 64
characters
Login
Password
FTP server log-in password Up to 64
characters
* To specify a port number different from the default (21), enter using
the format “host name: port number” (e.g., FTPhostname: 140).

Kyocera ECOSYS FS-1135MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Standard Memory	256 MB
Connectivity	USB 2.0, Ethernet
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Maximum Paper Size	A4
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	494 x 430 x 448 mm
Print Speed	35 ppm
Standard Input Capacity	250 sheets
Copy Speed	Up to 35 cpm
Maximum Input Capacity	800 sheets (with optional paper feeders)
