Preparation before Use
2-12
16 Press the Y or Z key to move the cursor position, press
the U or V key to enter hours, minutes and seconds,
and then press the OK key.
Completed. is displayed and the screen returns to the
Date Setting menu.
17 Press the U or V key to select [Date Format].
18 Press the OK key. Date Format appears.
19 Press the U or V key to select the desired display
format and then press the OK key.
Completed. is displayed and the screen returns to the
Date Setting menu.
Date/Time: a b
Hour
Min. Second
11:
45: 50
(Time Zone:Greenwich)
Date Setting: a b
1 Date/Time
*********************
3 Time Zone
[ Exit ]
2 Date Format
Date Format: a b
1 Month/Day/Year
*********************
3 Year/Month/Day
[ Exit ]
2 *Day/Month/Year

Kyocera ECOSYS FS-1135MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Standard Memory	256 MB
Connectivity	USB 2.0, Ethernet
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Maximum Paper Size	A4
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	494 x 430 x 448 mm
Print Speed	35 ppm
Standard Input Capacity	250 sheets
Copy Speed	Up to 35 cpm
Maximum Input Capacity	800 sheets (with optional paper feeders)
