Preparation before Use
2-44
3 Adjust the position of the paper guides on the MP tray.
Standard paper sizes are marked on the MP tray or
Manual Feed tray. For standard paper sizes, slide the
paper guides to the corresponding mark.
4 Align the paper with the paper guides and insert as far as
it will go.
IMPORTANT: Keep the side that was closest the package
seal facing up.
Curled paper must be uncurled before use.
Straighten the top edge if it is curled.
When loading paper into the multi purpose tray, check that
there is no paper left over in the tray from a previous job
before loading the paper. If there is just a small amount of
paper left over in the multi purpose tray and you want to add
more, first remove the left-over paper from the tray and
include it with the new paper before loading the paper back
into the tray.
Loading Envelopes
1 envelope may be loaded in the multi purpose tray.
Acceptable envelope sizes are as follows.
Acceptable Envelope Size
Hagaki 100 × 148 (mm)
Oufuku Hagaki 148 × 200 (mm)
Youkei 2 114 × 162 (mm)
Youkei 4 105 × 235 (mm)
Monarch 3 7/8" × 7 1/2"
Envelope #10 (Commercial #10) 4 1/8" × 9 1/2"
Envelope DL 110 × 220 (mm)
Envelope C5 162 × 229 (mm)
Executive 7 1/4" × 10 1/2"
Envelope #9 (Commercial #9) 3 7/8" × 8 7/8"
Envelope #6 (Commercial #6 3/4) 3 5/8" × 6 1/2"

Kyocera ECOSYS FS-1135MFP Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Standard Memory	256 MB
Connectivity	USB 2.0, Ethernet
Scanner Type	Flatbed, ADF
Scan Resolution	600 x 600 dpi
Copier Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Maximum Paper Size	A4
Operating System Compatibility	Windows, Mac OS, Linux
Dimensions	494 x 430 x 448 mm
Print Speed	35 ppm
Standard Input Capacity	250 sheets
Copy Speed	Up to 35 cpm
Maximum Input Capacity	800 sheets (with optional paper feeders)
