Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-33
J0509 No paper feed from the MP
tray
Condition: Paper is damaged (Paper is caught
up, the paper conveying force is lowered or paper
slips).
J0509 No paper feed from the MP
tray
Condition: Paper is not damaged (The MP bottom
plate does not ascend or feed drive does not
start).
J0511 Multi feed jam
J0512/J0513 Multi feed jam
J0518 Multi-feeding from the duplex
section
J0519 Multi-feeding from the MP
tray
J1403 PF feed sensor non-arrival
jam
Target: Paper feeder 2
Condition: Paper is not damaged (Paper feed
does not start or the PF conveying clutch does
not operate properly).
J1403 PF feed sensor non-arrival
jam
Target: Paper feeder 2
Condition: Paper is damaged (Paper is caught
up, the paper conveying force is lowered or paper
slips).
J1413 PF feed sensor stay jam Target: Paper feeder 2
J4002/J4003 Registration sensor non-
arrival jam
Condition: Paper is damaged.
J4002/J4003 Registration sensor non-
arrival jam
Condition: Paper is not damaged. (The PF con-
veying roller does not rotate properly. The PF
conveying clutch does not operate properly.)
J4008 Registration sensor non-
arrival jam
J4012/J4013/J4018 Registration sensor stay jam
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper jam before the fuser section
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper jam in the fuser section
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper rolled up on the fuser roller
(leading edge margin less than 4.0mm)
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper rolled up on the fuser roller
(leading edge margin 4.0mm or more)
J4201/J4202/J4203/
J4208/J4209
Exit sensor non-arrival jam Condition: Paper jam after passing the lower exit
roller
J4211/J4212/J4213/
J4218/J4219
Exit sensor stay jam Condition: Paper jam in the fuser section
J4211/J4212/J4213/
J4218/J4219
Exit sensor stay jam Condition: Paper jam in the exit unit
J4211/J4212/J4213/
J4218/J4219
Exit sensor stay jam Condition: Paper jam at FD guide
Error code Contents note

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
