Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-39
J0501: Cassette no feed
Condition: The paper conveying force is lowered and paper slips.
When feeding from cassette1, the paper leading edge gets out of cassette but does not reach the middle roller
after the feed clutch turns on.
J0502/J0503: Cassette no feed
Condition: The paper conveying force is lowered and paper slips.
When feeding from cassette 2,3, the paper leading edge gets out of cassette but does not reach the PF con-
veying roller after the PF feed clutch turns on.
2 Reattaching the retard
spring
The retard spring comes
off.
Reattach the retard spring.
3 (In case paper is bent or
conveyed in skew) Check-
ing the conveying path
Paper is caught up by the
conveying guide or paper
piece.
If there is a paper piece or
foreign object on the convey-
ing side or a burr on the con-
veying side of the conveying
guide or on the parts such as
actuator, remove it or replace
it. If there is a scratch, defor-
mation or floating on the
sheet or film, correct or
replace it.
Step Check description Assumed cause Measures Reference
1 Checking the retard roller The conveying perfor-
mance is lowered due to
the retard roller rotation
failure.
Clean the retard roller sur-
face. If worn down, replace it.
2 Checking the retard holder The load increases since
the retard holder is caught
up.
Reattach the retard holder. If
not repaired, replace it.
3 Checking the paper feed
roller
The conveying function of
the paper feed roller is not
enough.
Clean the paper feed roller
surface. If worn down,
replace it.
4 (When the paper skew
occurs) Relocating the
paper width guides
The locations of the paper
width guides do not fit with
the paper size.
Relocate the paper width
guides to fit them with the
paper size.
5 (In case paper is conveyed
in skew) Checking the
paper stacking level
Paper is loaded above the
highest level.
Reload paper up to the paper
stack limit label level.
Step Check description Assumed cause Measures Reference
1 Checking the retard roller The conveying perfor-
mance is lowered due to
the retard roller rotation
failure.
Clean the retard roller sur-
face. If worn down, replace it.
Step Check description Assumed cause Measures Reference

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
