Kyocera Ecosys P2235dw Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-63
J4201/J4202/J4203/J4208/J4209: Exit sensor non-arrival jam
Condition: Paper rolled up on the fuser roller (leading edge margin 4.0mm or more)
When feeding from cassette 1-3, duplex or MP tray, paper is rolled up along the fuser roller and the exit sen-
sor does not turn on.
J4201/J4202/J4203/J4208/J4209: Exit sensor non-arrival jam
Condition: Paper jam after passing the lower exit roller
When feeding from cassette 1-3, duplex or MP tray, paper jams after passing through the lower exit roller and
the exit sensor does not turn on.
2 (When the paper skew
occurs) Relocating the
paper width guides
The locations of the paper
width guides do not fit with
the paper size.
Relocate the paper width
guides to fit them with the
paper size.
3 Replacing the paper The paper curls. Replace with long grain
paper.
4 Checking the paper The paper leading edge is
bent.
Remove the bent paper.
5 Checking the paper The paper is wavy. Correct or replace paper. If
difficult to replace, re-load
paper by switching top and
bottom ends or turning it over.
6 Checking the paper Unspecified papers are
used.
Explain to the user to use the
paper within the specifica-
tions.
7 Checking the paper foreign objects are on the
paper.
Remove the paper with for-
eign objects.
8 Checking the press roller
and fuser belt
Foreign objects adhere to
the press roller or fuser
belt.
Clean the press roller and
fuser belt. Or replace the
fuser unit.
Step Check description Assumed cause Measures Reference
1 Checking the press roller
and fuser belt
Foreign objects adhere to
the press roller or fuser
belt.
Clean the press roller or
replace the fuser unit.
Step Check description Assumed cause Measures Reference
1 (When the paper skew
occurs) Checking the actu-
ator and the spring
The actuator does not
operate properly.
Reattach the exit sensor
actuator and spring. If not
operating properly due to
deformation, correct or
replace them.
2 (In case paper is conveyed
in skew) Checking the
fuser exit guide
The fuser exit guide is
deformed.
Reattach the fuser exit guide.
If the conveying side of the
fuser exit guide is warped,
correct it. If not repaired,
replace the fuser unit.
Step Check description Assumed cause Measures Reference

Kyocera Ecosys P2235dw Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	6.8 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Duplex print speed (black, normal quality, A4/US Letter)	17 ppm
Printer fonts	Barcode, Bitmap, TrueType, Windows
Printing colors	Black
Maximum duty cycle	20000 pages per month
Recommended duty cycle	1500 - 2500 pages per month
Replacement cartridges	TK-1150 (3.000 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCXL
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	105 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Maximum internal memory	256 MB
Sound pressure level (printing)	47.9 dB
Sound pressure level (quiet mode)	44.8 dB
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Kyocera Mobile Print
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	TÜV/GS, CE, ISO
Product color	White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	8 W
Power consumption (standby)	0.8 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.36 kWh/week
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	1000 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
