Kyocera FS-1028MFP

2H9
2-1-6
2-1-3 Optical section
(1) Scanner unit
Figure 2-1-10Scanner unit
1
3
7
8
9
5
10
4
6
2
(1) ISU top frame
(2) ISU bottom frame
(3) Contact glass
(4) DP contact glass
(5) Size indicator plate
(6) ISU belt
(7) ISU shaft
(8) ISU gear 63/32
(9) ISU motor
(10) Image scanner unit (ISU)
