4-41
Operation Panel
Duplex (Setting the duplex printing)
Using the duplexer, you can automatically print on both sides of the paper.
Duplex printing is available for the following paper (media) types:
Plain
Preprinted
Bond
Recycled
Rough
Letterhead
Color
Prepunched
High Quality
Custom 1 to 8
Binding Modes
Binding refers to the manner in which printed pages of paper are joined together (by gluing, stitching, etc.) in book form.
The two possible types of binding are: Bind Long Edge, in which pages are joined together along their long edge; and Bind
Short Edge, in which they are joined together along their short edge. In selecting a binding type, you must also consider the
orientation of the printed page. You can use Bind Long Edge or Bind Short Edge with either landscape or portrait printing.
Depending on the binding type and print orientation, the duplexer provides four types of binding. These are: (1) portrait, Bind
Long Edge, (2) portrait, Bind Short Edge, (3) landscape, Bind Long Edge, and (4) landscape, Bind Short Edge. The figure
below shows these binding methods.
1 In the Print Settings menu, press U or V to select Duplex.
2 Press [OK]. The Duplex screen appears showing the list of available
duplex printing modes.
3 Press U or V to select the desired duplex printing mode.
The message display toggles through the following:
Off (default)
Note Duplex printing can be also performed from the MP tray. If the paper to be fed from the MP tray does not
match the paper size and paper type of the current paper feed source cassette, a paper jam may occur.
When Custom is specified, duplex printing can be set. For details, refer to Custom Paper Settings on page 4-36.
To Next Page
