Kyocera FS-C5150DN Service Manual

2KT/2KV
1-4-4
0514 Multiple sheets in cassette 4 PF feed sensor 3 (PFFS3) does not turn off during
paper feed from paper feeder 3.
H
0518 Multiple sheets in duplex
section
The registration sensor (RS) does not turn off dur-
ing paper feed from duplex section.
E
0519 Multiple sheets in MP tray MP feed sensor (MPFS) does not turn off during
paper feed from MP tray.
B
1020 MP feed sensor remaining
jam
MP feed sensor (MPFS) is turned on when the
power is turned on.
B
1403 PF feed sensor 1 non arrival
jam
PF feed sensor 1 (PFFS1) does not turn on during
paper feed from paper feeder 2.
F
1404 PF feed sensor 1 (PFFS1) does not turn on during
paper feed from paper feeder 3.
F
1413 PF feed sensor 1 stay jam PF feed sensor 1 (PFFS1) does not turn off during
paper feed from paper feeder 2.
F
1414 PF feed sensor 1 (PFFS1) does not turn off during
paper feed from paper feeder 3.
F
1420 PF feed sensor 1 remaining
jam
PF feed sensor 1 (PFFS1) is turned on when the
power is turned on.
F
1604 PF feed sensor 2 non arrival
jam
PF feed sensor 2 (PFFS2) does not turn on during
paper feed from paper feeder 3.
G
1614 PF feed sensor 2 stay jam PF feed sensor 2 (PFFS2) does not turn off during
paper feed from paper feeder 3.
G
1620 PF feed sensor 2 remaining
jam
PF feed sensor 2 (PFFS2) is turned on when the
power is turned on.
G
1820 PF feed sensor 3 remaining
jam
PF feed sensor 3 (PFFS3) is turned on when the
power is turned on.
H
4002 Registration sensor non
arrival jam
The registration sensor (RS) does not turn on dur-
ing paper feed from paper feeder 1.
A
4003 The registration sensor (RS) does not turn on dur-
ing paper feed from paper feeder 2.
A
4009 The registration sensor (RS) does not turn on dur-
ing paper feed from MP tray.
A
4012 Registration sensor stay jam The registration sensor (RS) does not turn off dur-
ing paper feed from paper feeder 1.
C
4013 The registration sensor (RS) does not turn off dur-
ing paper feed from paper feeder 2.
C
4014 The registration sensor (RS) does not turn off dur-
ing paper feed from paper feeder 3.
C
4019 The registration sensor (RS) does not turn off dur-
ing paper feed from MP tray.
C
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-2 for paper jam location (see page 1-4-2).

Kyocera FS-C5150DN Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Maximum duty cycle	50000 pages per month
Number of print cartridges	4
Memory type	DDR
Memory slots	1
Processor model	PowerPC 464
Maximum internal memory	1280 MB
Sound power level (standby)	50 dB
Display	-
Total input capacity	250 sheets
Total output capacity	- sheets
Multi-Purpose tray input capacity	50 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Photo paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Letterhead, Recycled paper
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
Mac operating systems supported	Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	- W

Weight and Dimensions

Dimensions (WxDxH)	391 x 523 x 371 mm
