Kyocera FS-C5350DN Service Manual

2K8
1-3-15
Service items Description
No. Items Description
 Paper
Jam
Log
# Count. Event
Remembers 1 to 16 of occurrence.
If the occurrence of the previous
paper jam is less than 16, all of the
paper jams are logged. When the
occurrence excessed 16, the old-
est occurrence is removed.
The total page
count at the time
of the paper
jam.
Log code (2 digit, hexadecimal, 5 cate-
gories)
(a) Cause of a paper jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper exit
(a) Cause of paper jam
10: Paper does not arrive at the registration sensor. [B] (MP tray)
10: Paper does not arrive at the registration sensor. [1] (Printer’s cassette)
10: Paper does not arrive at the registration sensor. [1] (Paper feeder 1)
10: Paper does not arrive at the registration sensor. [1] (Paper feeder 2)
10: Paper does not arrive at the registration sensor. [1] (Paper feeder 3)
10: Paper does not arrive at the registration sensor. [I] (Duplex conveying)
11: Paper does not pass the registration sensor. [H]
12: Paper remains at the registration sensor when power is turned on. [H]
20: Paper does not arrive at the paper exit sensor. [H]
21: Paper does not pass the paper exit sensor. [G]
22: Paper remains at the paper exit sensor when power is turned on. [G]
30: Paper does not arrive at the paper feeder 1’s PF paper feed sensor. [2] (Paper feeder 1)
30: Paper does not arrive at the paper feeder 1’s PF paper feed sensor. [3] (Paper feeder 2)
30: Paper does not arrive at the paper feeder 1’s PF paper feed sensor. [3] (Paper feeder 3)
31: Paper does not pass the paper feeder 1’s PF paper sensor. [2]
32: Paper remains at the paper feeder 1’s PF paper feed sensor when power is turned on. [2]
40: Paper does not arrive at the paper feeder 2’s PF paper feed sensor. [3] (Paper feeder 2)
40: Paper does not arrive at the paper feeder 2’s PF paper feed sensor. [4] (Paper feeder 3)
41: Paper does not pass the paper feeder 2’s PF paper sensor. [3]
42: Paper remains at the paper feeder 2’s PF paper feed sensor when power is turned on. [3]
50: Paper does not arrive at the paper feeder 3’s paper feed sensor. [4] (Paper feeder 3)
51: Paper does not pass the paper feeder 3’s paper sensor. [4]
52: Paper remains at the paper feeder 3’s PF paper feed sensor when power is turned on. [4]
A0: Paper does not arrive at the duplex sensor. [I]
A1: Paper does not pass the duplex sensor. [I]
A2: Paper remains at the duplex sensor when power is turned on. [I]
E0: Paper misfeed occurs due to forced stop when an error occurs during printing. (such as
opening of a cover)
F0: Paper does not arrive at the face down tray paper full sensor. [G]
F1 to FF: Paper misfeed by another cause.
Values (hexadecimal) within [ ] indicate paper misfeed locations.

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
