Kyocera FS-C5350DN Service Manual

2K8
1-4-18
7412 Drum unit C non-installing error
The EEPROM of drum PWB C does not
communicate normally.
Incompatible drum unit C is installed.
Faulty connection
of the connector
between the drum
PWB C and drum
relay PWB.
Check the installation of the drum unit C and
drum relay PWB and reinstall them if neces-
sary (See page 1-5-14).
Defective harness
between drum
relay PWB (YC1)
and engine PWB
(YC34), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Installation of
incompatible drum
unit C.
Install drum unit C compatible with the spec-
ifications to the printer.
Defective drum
PWB C.
Replace the drum unit C (See page 1-5-14).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
7413 Drum unit M non-installing error
The EEPROM of drum PWB M does not
communicate normally.
Incompatible drum unit M is installed.
Faulty connection
of the connector
between the drum
PWB M and drum
relay PWB.
Check the installation of the drum unit M and
drum relay PWB and reinstall them if neces-
sary (See page 1-5-14).
Defective harness
between drum
relay PWB (YC1)
and engine PWB
(YC34), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Installation of
incompatible drum
unit M.
Install drum unit M compatible with the spec-
ifications to the printer.
Defective drum
PWB M.
Replace the drum unit M (See page 1-5-14).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
