2K8
1-2-3
120 V AC model
Figure 1-2-3 120 V AC model
11
22
22
22
22
2
21
20
3
4
5
13
15
16
17
18
19
1
14
21
12
6
7
8
9
10
1. Printer
2. Toner container (Yellow)
3. Toner container (Black)
4. Toner container (Cyan)
5. Toner container (Magenta)
6. Waste toner box
7. Power cord
8. Document tray
9. Upper left cushion
10. Upper right cushion
11. Outer case
12. Machine cover 600 × 600 × 900
13. Cassette cushion
14. Desiccating agent
15. Main pad
16. Machine cover 650 × 650 × 1200
17. Bottom left cushion
18. Bottom right cushion
19. Toner pad US
20. Plastic bag 240 × 350
21. Operation guide
22. Plastic bags 200 × 700
