PF paper feed motor error
(Option paper feeder)
The PF paper feed motor of paper feeder
1 ready input is not given for 2 seconds
during the PF paper feed motor is ON.
2610: Paper feeder 1
2620: Paper feeder 2
2630: Paper feeder 3
Defective harness
between PF paper
feed motor and PF
main PWB (YC6),
or improper con-
nector insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to the
service manual for the paper feeder).
Defective PF paper
feed motor drive
transmission
system.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any. (Refer to
the service manual for the paper feeder).
Defective PF main
motor.
Replace the PF main motor.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Defective printer’s
engine PWB.
Replace the printer’s engine PWB (Refer to
the service manual for the printer).
2830 Developing motor K error
The ready signal cannot be detected
within 5 seconds after the developing
motor K turns on.
Defective harness
between develop-
ing motor K and
engine PWB
(YC26), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness (Refer to the
service manual for the paper feeder).
Defective drive
transmission
system of the
developing motor
K.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Improper installa-
tion intermediate
transfer unit.
Check the installation of the intermediate
transfer unit and reinstall them if necessary
(See page 1-5-16).
Defective develop-
ing motor K.
Replace the developing motor K.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
4001 Polygon motor YK error
The polygon motor YK ready input is not
given for 10 seconds during the polygon
motor YK is ON.
Defective harness
between polygon
motor YK and
engine PWB
(YC29), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective laser
scanner unit YK.
Replace the laser scanner unit YK (See
page 1-5-37).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
