Kyocera FS-C5350DN Service Manual

2K8
1-4-10
4002 Polygon motor MC error
The polygon motor MC ready input is not
given for 10 seconds during the polygon
motor MC is ON.
Defective harness
between polygon
motor MC and
engine PWB
(YC30), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective laser
scanner unit MC.
Replace the laser scanner unit MC (See
page 1-5-37).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
4201 Laser output error (Black)
The pin photo signal (PDN) is not output
from PD PWB K for one second while
laser is emitted.
Defective harness
between APC
PWB K and engine
PWB (YC29), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective APC
PWB K.
Replace the laser scanner unit YK (See
page 1-5-37).
Defective PD PWB
K.
Replace the laser scanner unit YK (See
page 1-5-37).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
4202 Laser output error (Cyan)
The pin photo signal (PDN) is not output
from PD PWB C for one second while
laser is emitted.
Defective harness
between APC
PWB C and engine
PWB (YC30), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective APC
PWB C.
Replace the laser scanner unit MC (See
page 1-5-37).
Defective PD PWB
C.
Replace the laser scanner unit MC (See
page 1-5-37).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
4203 Laser output error (Magenta)
The pin photo signal (PDN) is not output
from PD PWB M for one second while
laser is emitted.
Defective harness
between APC
PWB M and engine
PWB (YC30), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective APC
PWB M.
Replace the laser scanner unit MC (See
page 1-5-37).
Defective PD PWB
M.
Replace the laser scanner unit MC (See
page 1-5-37).
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
29).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-C5350DN Specifications

General

Color	Yes
Maximum resolution	9600 x 600 DPI
Time to first page (black, normal)	8.5 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Internal memory	256 MB
Processor model	PowerPC 750CL
Maximum internal memory	1280 MB
Sound power level (standby)	36 dB
Sound pressure level (printing)	55 dB
Total input capacity	150 sheets
Total output capacity	250 sheets
Maximum input capacity	2150 sheets
Maximum print size	210 x 297 mm
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Safety	GS, TÜV, CE
Power management	AC 220 - 240 V, 50/60 Hz
Custom media sizes	70 x 138 mm - 216 x 356 mm
Networking features	10/100BaseTX
Power consumption (active)	516 W
Compatible operating systems	Windows, Mac OS X 10.2, UNIX, LINUX
Maximum duty cycle	100000 pages per month
Power consumption (standby)	74 W
Power consumption (PowerSave)	8 W

Weight and Dimensions

Dimensions (WxDxH)	345 x 518 x 480 mm
