Kyocera FS-C5350DN

2K8
1-5-3
1-5-2 Outer covers
(1) Detaching and refitting the left rear cover, left upper cover and left front cover
Procedure
1. Open the left cover.
2. Remove the waste toner box.
3. Remove two screws.
Figure 1-5-3
Left cover
Waste toner box
Screw
Screw
