1-1-2 Parts names
(1) Overall
Figure 1-1-1
9
10
10
10
10
11
12
13
14
15
21
17
16
18
19
20
22
23
24
5
7
8
3
4
1
2
6
1. Operation panel
2. Front cover
3. Top cover (Top tray)
4. Paper stopper
5. MP tray
6. Cassette
7. Power switch
8. Left cover
9. Waste toner box
10. Main charger units
11. Toner container M
12. Toner container C
13. Toner container Y
14. Toner container K
15. Duplex unit B
16. Fuser cover A
17. Envelope switch
18. USB memory slot
19. USB interface
20. AC inlet
21. Optional interface slot
22. Network indicators
23. Network interface
24. Right cover
