2K8
1-3-5
Detail of service status page (2)
Service items Description
Code conversion
ABCDEF GHI J
0123456789
No. Items Description
NVRAM version _ 1F3 1225 _ 1F3 1225
(a) (b) (c) (d) (e) (f)
a) Consistency of the present software version and the database
_ (underscore): OK
* (Asterisk): NG
(b) Database version
(c) The oldest time stamp of database version
(d) Consistency of the present software version and the ME firmware ver-
sion
_ (underscore): OK
* (Asterisk): NG
(e) ME firmware version
(f) The oldest time stamp of the ME database version
Normal if (a) and (d) are underscored, and (b) and (e) are identical with (c)
and (f).
Mac address -
Destination information -
Area information -
Margin settings Top margin/Left margin
Low Power mode settings -
Top offset for each paper
source
MP tray/Paper feeder 1/Paper feeder 2/Paper feeder 3/ - /Duplex/
Page rotation
Left offset for each paper
source
MP tray/Paper feeder 1/Paper feeder 2/Paper feeder 3/ - /Duplex/
Page rotation
L value settings Top margin (integer)/Top margin (decimal place)/Left margin (integer)/Left
margin (decimal place)/Paper length (integer)/Paper length (decimal place)/
Paper width (integer)/Paper width (decimal place)/
Life counter (The first line)
Machine/MP tray/Printer’s cassette/Paper feeder 1/Paper feeder 2/
Paper feeder 3/ - /Duplex printing
Life counter (The second
line)
Drum unit K/Drum unit C/Drum unit M/Drum unit Y/
Intermediate transfer unit/Developing unit K/Developing unit C/
Developing unit M/Developing unit Y/Maintenance kit
Operation panel lock status 0: Off
1: Partial lock
2: Full lock
USB information 0: Not connected
1: Full-Speed
2: Hi-Speed
Paper handling information 0: Paper source unit select
1: Paper source unit
Color printing double count
mode
0: All single counts
3: Folio, Single count, Less the 330 mm (length)
Black and white printing
double count mode
0: All single counts
3: Folio, Single count, Less the 330 mm (length)
