(2) Detaching and refitting the main charger unit
Procedure
1. Open the left cover.
2. Remove the main charger units (M,C,Y and
K).
3. Check or replace the main charger units and
refit all the removed parts.
Figure 1-5-17
Left cover
K
Y
C
Main charger
unit M
