Kyocera KM-1650

2DA/2DB
1-5-3
Section Jam code Description Conditions
System 00 No paper feed When the power switch is turned on, the machine detects acti-
vation of the registration switch (RSW), the exit switch (ESW)
or the feedshift switch (FSSW).
04 Cover open JAM A cover open state is detected during copying.
05 Secondary paper feed
timeout
When the machine waits for secondary paper feed, 30 s or
more have elapsed.
Paper feed
section
10 No paper feed from the
bypass tray
The registration switch (RSW) does not turn on within 1680 ms
of the bypass paper feed solenoid (BYPPFSOL) turning on;
the solenoid is then successively held off for 1 s and turned
back on once, but the switch again fails to turn on within 1680
ms.
11 No paper feed from the
drawer 1 (drawer)
The registration switch (RSW) does not turn on within 1430 ms
of the paper feed clutch (PFCL) turning on;
the clutch is then successively held off for 1 s and turned back
on once, but the switch again fails to turn on within 1430 ms.
12 No paper feed from the
drawer 2*
2
(first paper
feeder)
The registration switch (RSW) does not turn on within 2780 ms
of the drawer paper feed clutch 1 (DPFCL1)*
2
turning on;
the clutch is then successively held off for 1 s and turned back
on once, but the switch again fails to turn on within 2780 ms.
13 No paper feed from the
drawer 3*
1
(second paper
feeder)
The drawer feed switch 1 (DFSW1)*
2
does not turn on within
2490 ms of the drawer paper feed clutch 2 (DPFCL2)*
1
turning
on; the clutch is then successively held off for 1 s and turned
back on once, but the switch again fails to turn on within 2490
ms.
14 No paper feed from the
drawer 4*
1
(third paper
feeder)
The drawer feed switch 2 (DFSW2)*
1
does not turn on within
2490 ms of the drawer paper feed clutch 3 (DPFCL3)*
1
turning
on; the clutch is then successively held off for 1 s and turned
back on once, but the switch again fails to turn on within 2490
ms.
15 Misfeed in vertical paper
conveying 1
The registration switch (RSW) does not turn on within 2340 ms
of drawer feed switch 1 (DFSW1)*
2
turning on.
The drawer feed switch 1 (DFSW1)*
2
does not turn off within
2050 ms of drawer feed switch 2 (DFSW2)*
1
turning on.
The drawer feed switch 1 (DFSW1)*
2
does not turn off within
2050 ms of drawer feed switch 2 (DFSW2)*
1
turning off.
16 Misfeed in vertical paper
conveying 2
The drawer feed switch 1 (DFSW1)*
2
does not turn on within
2050 ms of drawer feed switch 2 (DFSW2)*
1
turning on.
Paper
conveying
section
20 Multiple sheets in the
bypass tray
The registration switch (RSW) does not turn off within 6320 ms
of registration switch (RSW) turning on.
The registration switch (RSW) does not turn off within 1680 ms
of bypass paper feed solenoid (BYPPFSOL) turning on.
21 Multiple sheets in the
drawer 1 (drawer)
The registration switch (RSW) does not turn off within 6320 ms
of registration switch (RSW) turning on.
The registration switch (RSW) does not turn off within 1430 ms
of paper feed clutch (PFCL) turning on.
*1: Optional. *2: Optional for 16 ppm model. Standard for 20 ppm model.
