2DA/2DB
1-5-10
(8)
A paper jam in the
paper feed section is
indicated during
copying (misfeed in
vertical paper con-
veying 2).
Jam code 16
Broken drawer feed switch
1*
2
actuator.
Check visually and replace drawer feed switch 1 if its actuator is
broken.
Defective drawer feed
switch 1*
2
.
Run maintenance item U031 and turn drawer feed switch 1 on
and off manually. Replace drawer feed switch 1 if indication of the
corresponding switch is not light.
Broken drawer feed switch
2*
1
actuator.
Check visually and replace drawer feed switch 2 if its actuator is
broken.
Defective drawer feed
switch 2*
1
.
Run maintenance item U031 and turn drawer feed switch 2 on
and off manually. Replace drawer feed switch 2 if indication of the
corresponding switch is not light.
Check if the drawer paper
feed clutch 1*
2
malfunc-
tions.
Run maintenance item U032 and select the drawer paper feed
clutch 1 to be turned on and off. Check the status and remedy if
necessary.
Electrical problem with the
drawer paper feed clutch
1*
2
.
Check.
Check if the drawer paper
feed clutch 2*
1
malfunc-
tions.
Run maintenance item U032 and select the drawer paper feed
clutch 2 to be turned on and off. Check the status and remedy if
necessary.
Electrical problem with the
drawer paper feed clutch
2*
1
.
Check.
(9)
A paper jam in the
paper conveying sec-
tion is indicated dur-
ing copying (multiple
sheets in the bypass
tray).
Jam code 20
Deformed guides along the
paper conveying path.
Repair or replace if necessary.
Broken registration switch
actuator.
Check visually and replace registration switch if its actuator is bro-
ken.
Defective registration
switch.
Run maintenance item U031 and turn registration switch on and
off manually. Replace registration switch if indication of the corre-
sponding switch is not light.
Check if the bypass paper
feed solenoid malfunctions.
Run maintenance item U032 and select the bypass paper feed
solenoid to be turned on and off. Check the status and remedy if
necessary.
Electrical problem with the
bypass paper feed sole-
noid.
Check (see page 1-5-35).
Check if the right and left
registration rollers contact
each other.
Check visually and remedy if necessary.
(10)
A paper jam in the
paper conveying sec-
tion is indicated dur-
ing copying (multiple
sheets in the drawer
1).
Jam code 21
Deformed guides along the
paper conveying path.
Repair or replace if necessary.
Broken registration switch
actuator.
Check visually and replace registration switch if its actuator is bro-
ken.
Defective registration
switch.
Run maintenance item U031 and turn registration switch on and
off manually. Replace registration switch if indication of the corre-
sponding switch is not light.
Check if the paper feed
clutch malfunctions.
Run maintenance item U032 and select the paper feed clutch to
be turned on and off. Check the status and remedy if necessary.
*1: Optional. *2: Optional for 16 ppm model. Standard for 20 ppm model.
Problem
Causes/check procedures
Corrective measures
