2DA/2DB
1-3-4
1. Install the optional paper feeder as necessary (see pages 1-3-7 to 1-3-8).
1. Remove the ten tapes (16 ppm model).
Remove the fifteen tapes (20 ppm model)..
Figure 1-3-2
2. Remove the two pins for light source unit.
Figure 1-3-3
Install the optional paper feeder.
Remove the tapes and pins.
Tap es
Tap es
Tap e
Tap es
Tap es
Tap es
Tap es
Tap es
Tap e
Tap es
Tap e
Tap e
16 ppm model
20 ppm model
Tap e
Pins
