Kyocera KM-2020

2C9
1-1-5
1 Paper feed section
2 Optical section
3 Drum section
4 Developing section
5 Transfer and separation section
6 Fixing section
7 Exit and switchback section
8 Duplex section
Figure 1-1-3 Machine cross section
1-1-3 Machine cross section
Light path
Paper path
