Kyocera KM-2020

2C9-3
2-4-8
Maintenance parts list
Maintenance part name
Part No. Fig. No. Ref. No.
Name used in service manual Name used in parts list
Paper feed pulley PULLEY, PAPER FEED 2AR07220 5 39
Separation pulley PULLEY, SEPARATION 2AR07230 5 40
Forwarding pulley PULLEY, LEADING FEED 2AR07240 5 41
Bypass paper feed pulley PULLEY BYPASS 2C906180 6 19
Bypass separation pad SHEET BYPASS PAD 2C906160 6 17
Left registration roller ROLLER REGIST LEFT 2C916020 4 1
Right registration roller RIGHT ROLL REGIST 2C907180 5 9
Registration cleaner RIGHT CLEANER REGIST 2C907450 5 27
Trans guide film FILM RIGHT TRANS GUIDE 2C917190 5 28
Slit glass CONTACT GLASS ADF 2C912280 8 27
Contact glass CONTACT GLASS 2C912250 8 24
Mirror 1 MIRROR A 2C912390 8 37
Mirror 2 and mirror 3 MIRROR B 2AV12160 8 4
Lens LENS 2C912500 – –
Reflector REFLECTOR SCANNER 2C912110 8 12
Exposure lamp LAMP SCANNER YG 2C912090 8 10
Front scanner rail FRONT RAIL SCANNER 2C912070 – –
Rear scanner rail REAR RAIL SCANNER 2C912080 – –
Original size detection sensor SENSOR ORIGINAL 2C912090 8 55
Transfer roller ROLLER TRANSFER 2C917010 4 21
Separation electrode PLATE STA ELIMINATION 2C917080 4 28
Developing unit PARTS, DV-410, SP 2C993030 9 1
Drum unit SET MK-410 2C982010 9 5
Fixing unit PARTS, FK-410(A), SP 2C993050 10 –
Fixing unit PARTS, FK-410(E), SP 2C993060 10 –
Heat roller ROLLER HEAT 2C920050 10 5
Press roller ROLLER PRESS 2C920060 10 6
Heat roller separation claw SEPARATOR ASSY 2BR20240 10 24
Exit roller ROLLER EXIT INNER 2C921010 7 17
Exit pulley PULLEY EJECT 2C921360 7 46
Switchback roller ROLLER FEED SHIFT 2C921020 7 18
Switchback pulley PULLEY FEED SHIFT 2C921040 7 19
