Kyocera KM-2020

2C9
2-3-13
Connector Pin No. Signal I/O Description
YC21
Connected
to the
power
source PCB
YC22
Connected
to the paper
size length
switch and
toner
container
detection
switch
YC24
Connected
to the
registration
motor PCB
9 SLEPN O Power source sleep signal
10 ZCROSS O Zero-cross signal
11 S.GND - Ground
12 +24 V2 I LCSSW on/off
13 S.GND - Ground
14 +5 V3 I FCSSW on/off
1 C1PLSW3N I PLSW on/off
2 C1PLSW2N I PLSW on/off
3 S.GND - Ground
4 C1PLSW1N I PLSW on/off
5 TCONDET I TCDSW on/off
6 S.GND - Ground
1 +24 V4 O 24 V DC power supply for RMPCB
2 S.GND - Ground
29 GND - Ground
