2 PRINTING FROM WINDOWS
56 Setting Up Print Options
¦ [Configuration] tab
The [Configuration] tab allows you to configure options. When any optional unit is installed in this equipment, set the
configuration of the machine on this tab. The [Configuration] tab can be displayed only from the Printers folder (and not
displayed when displaying the properties from the application’s print dialog box).
To perform settings on the [Configuration] tab menu, you need to select the printer driver of this equipment on the
Printers folder, and then click [File] menu, [Run as administrator] and select [Properties].
Enter the administrator password if required.
- If the [File] menu is not displayed, press [Alt].
- If the [User account control] dialog box is displayed, click [Continue] in this dialog box.
1) Model Selection
This sets the model name of the equipment.
- HS7565/HS6565/HS5555
2) Drawers
This sets whether or not the drawers or Large Capacity Feeder are installed.
- None — Select this when neither drawer nor Large Capacity Feeder is installed.
- LCF — Select this when the Large Capacity Feeder is installed.
3) External LCF
This sets whether or not the External Large Capacity Feeder (optional) is installed.
- None — Select this when a External Large Capacity Feeder (optional) is not installed.
- External LCF
— Select this when a External Large Capacity Feeder (optional) is installed.
4) Finisher
This sets whether or not the Finisher (optional) is installed.
- None — Select this when a Finisher (optional) is not installed.
- Finisher — Select this when a Finisher (optional) is installed.
- Saddle Stitch Finisher
— Select this when a Saddle Stitch Finisher (optional) is installed.
5) Hole Punch Unit
This sets whether or not the Hole Punch Unit (optional) is installed.
- None — Select this when a Hole Punch Unit (optional) is not installed.
- 2 Holes — Select this when a 2 Hole Punch Unit (optional) is installed.
- 2/3 Holes
— Select this when a 2/3 Hole Punch Unit (optional) is installed.
- 4 Holes (F) — Select this when a 4 hole (F) punch unit (optional) is installed.
- 4 Holes (S) — Select this when a 4 hole (S) punch unit (optional) is installed.
To Next Page
