2.HOW TO MAKE COPIES
Bypass Copying 49
2 HOW TO MAKE COPIES
4
Key in the dimension.
1) Press [Length] and key in the value. (100 mm (3.94") to 297 mm (11.69"))
2) Press [Width] and key in the value. (148 mm (5.83") to 432 mm (17.01"))
3) Press [OK].
To call up the dimension data registered previously, press the desired button from [MEMORY 1] to [MEMORY 4],
and then press [OK].
To register dimension data into the memory, see the following page:
P.50 “Registering non-standard size in the memory”
5
Select other copy modes as required, and then press the [START] button on the control
panel.
Length and width are indicated as shown on the right:
Width
Length
To Next Page
