KYORITSU KEW6024PV User Manual

 33 
- 33 -
Voltage:V
Resistance:RX
Current:I
LINE(-)
EARTH
(+)
Resistance=Voltage ／ Current
RX=V ／ I
CAUTION
● Always disconnect power to the conductor under test before starting
insulation measurement. Do not attempt to make measurements on a
live conductor. Otherwise, it may damage the instrument.
Fig. 8-2
Fig. 8-3
Fig. 8-4
The LCD shows “>2099MΩ” when the measured result exceeds the
display range (over-range).
Display example
Earth terminal
Black
Red
Power
Load
OFF
Switch
Principle of insulation resistance
measurement
