Chapter 3: Getting Started
Product Service 1-800-522-7658
have a number 1, 2, 3, 4 or 5 as to the location of the fan module. From
left to right facing the superstructure, fan 1 will be to the left, then 2, 3, 4,
and 5 to the right depending on the size.
5. Each Protector Hood will have the following Neutrodine filters based on
their size per each hood installed.
M1 (1 column filtration) 2 total Neutrodine filters
M2 (2 column filtration) 4 total Neutrodine filters
M3 (3 column filtration) 6 total Neutrodine filters
M4 (4 column filtration) 8 total Neutrodine filters
M5 (5 column filtration) 10 total Neutrodine filters
Step 2 – Locate cardboard box on the pallet, the controller on the front header,
the temperature sensor inside the hood, and the sash sensor on the left side.
For your convenience, the cardboard box on the pallet contains the operational
cards to run the hood along with the modular fan and light harnesses and air
sampling tubing. Please locate these now. Then locate the pre-mounted controller
on the front header, the temperature sensor inside the hood, and the sash sensor on
the left side of the hood. These components have been pre-mounted for
convenience. Note: See Figure 3-3 on page 21 that depicts the sash sensor for all
models and the rotated Filtration Technology applicable to only the 3' x 31.7"
Airo, model numbers 1843000-xx.
Step 3 – Install Card Holder and locate Admin, User and Maintenance
Cards.
Card holder snaps into control panel. See Figure 3-3. Cards and card holder are
located in important contents cardboard box.
Step 4 – Unpack all the filters.
Unpack all of the Neutrodine filters for the hood you are commissioning. The
Neutrodine filters are shipped separately from the filter manufacturer to your job
site. Remove all packing material, lay them flat and stack them out of the way of
the front of the superstructure but near it.
Step 5 – Unpack lights, put up gutters, light box and pre-filters.
On the top of the opened box you will find a rectangle “gutter.” Place that on top
of the superstructure first.
With gutter on, next put up the light out of that same box. Make sure that the
edge of the light box is properly seated into the foam of the gutter on all sides.
Now make sure the light has a white pre-filter inside the light box itself.
