Chapter 3: Getting Started
Product Service 1-800-522-7658
23
Original instructions
Step 11 – Install the light wires.
Now install the light wires connecting all the lights together. The sequence is top
left to bottom right. Then top left to bottom right until all the lights are
connected. The notched groove on the connector is always to the top.
Notched
groove
to top
Light
wiring
out
Light
wiring in
