36
OA-PRESENCE T DIP SWITCH SETTINGS
DIP 10 = ON Test input Low
For information about the adjustments and the other functional
settings of the sensor, please refer to the instructions supplied
with the OA‑PRESENCE T sensor.
FUNCTIONAL SETTINGS OF SELECTOR ET-DSEL
F14 (S07) = ON If the safety sensor is installed on E.O.1
F15 (S08) = ON If the safety sensor is installed on E.O.2
F17 (S10) = ON Opening safety sensor test enabled
F18 (S11) = OFF Test level LOW
17.3) SENSOR OA-PRESENCE T
Application as opening side safety sensor
OA-PRESENCE T SENSOR WIRING ETERNA 150 AUTOMATION ET-LOGIC-B TERMINAL BOARD
Correspondence between the sensor cables and the terminal board of the automation ETERNA 150 of the control unit
ET-LOGIC-B
1. RED (+) Power supply TERMINAL 22 (+)
2. GREEN (‑) Power supply TERMINAL 21 (‑)
5. BLUE + Opto NPN (sensor 1 safety) TERMINAL 8 E.O.1 Opening safety sensor 1
BLUE + Opto NPN (sensor 2 safety) TERMINAL 9 E.O.2 Opening safety sensor 2
6. WHITE ‑ COM (sensor 1 safety)
WHITE ‑ COM (sensor 2 safety)
TERMINAL 7 COMMON
7. BROWN (+) Test TERMINAL 20 TEST (+)
8. ORANGE (‑) Test TERMINAL 21 (‑)
The safety sensor operation test is carried out at the beginning of each door opening and closing cycle.
Should the sensor fail to properly respond to the test request by the automation control unit, the control unit buzzer will
beep and the leaf motion speed will be slow throughout the entire run.
