Label ETERNA 150 User Manual

60
TABELLA 1 - TABLE 1 - TABLEAU 1 - TABLA 1
trasmettitori Label - Label transmitters - transmetteurs Label - transmisores Label
ROLLING CODE DIP-SWITCH
SPYCO/1E
SPYCO/3E
MDW/1E
MDW/2E
TYKO/1E
TYKO/2E
RJW/1E
RJW/2E
RJW/4E
RJW/12E
SIGNIFICATO LED - LED MEANING - SIGNIFICATION LED - SIGNIFICADO DEL DIODO EMISOR DE LUZ
LED SPENTO - LED OFF - LED ÉTEINTE - DIODO EMISOR DE LUZ APAGADO
LED ACCESO - LED ON - LED ALLUMÉE - DIODO EMISOR DE LUZ ENCENDIDO
LED LAMPEGGIANTE LENTO - LED BLINKING SLOW - LED À CLIGNOTEMENT LENT
DIODO EMISOR DE LUZ DESTELLANDO LENTO
memorizzazione dei trasmettitori rolling code (SPYCO) - saving of rolling code (SPYCO) transmitters under
way mémorisation des transmetteurs rolling code (SPYCO) - memorización de los transmisores rolling code
(SPYCO)
LED LAMPEGGIANTE VELOCE - LED BLINKING FAST - LED À CLIGNOTEMENT RAPIDE
DIODO EMISOR DE LUZ DESTELLANDO RÁPIDO
memorizzazione di tutti i modelli di trasmettitori Label - saving of all Label transmitter models under way
mémorisation de tous les modèles de transmetteurs Label - memorización de todos los modelos de
transmisores Label
LED LAMPEGGIANTE MOLTO VELOCE - LED BLINKING VERY FAST - LED À
CLIGNOTEMENT TRÈS RAPIDE - DIODO EMISOR DE LUZ DESTELLANDO MUY RÁPIDO
cancellazione memoria - memory cancellation - e󰀨acement mémoire - borrado memoria
FIG. 1
FIG. 3
FIG. 2
ROLLING-CODE
TRANSMITTER
DIP-SWITCH
TRANSMITTER
29) FORCED CLOSING FUNCTION
To enable the “Forced closing” function, set the F52 function to ON.
When a N.C. contact is connected to the Stop/Interlock input (terminals 14‑19) it allows to forcibly close the door at slow speed after
device activation.
During this closing operation, all control and safety inputs are disabled.
Should the forced closing device still be active once the door is closed, the only way to open the door will be using a hold to run command
on the OPEN input (manned mode).

Label ETERNA 150 Specifications

General

Brand	Label
Model	ETERNA 150
Category	Home Automation
Language	English
