1) DESCRIPTION OF THE MODELS
The ETERNA 150 automation has been designed and manufactured for the control of pedestrian automatic sliding doors.
A list of the ETERNA 150 sliding door automation models produced by Label is provided below:
•
ETERNA 150D
Automation for double leaf doors, max. weight 150Kg./leaf.
•
ETERNA 150S
Automation for single leaf doors, max. weight 200Kg.
The choice of the model depends on the type of door to be automated (single- or double-leaf sliding door, or telescopic door equipped
with two or four movable leaves).
All ETERNA 150 automation models can be equipped with the battery for emergency opening and with the electric lock.
The automation must be installed in indoor environments.
MECHANICAL COMPONENTS OF THE SLIDING DOOR AUTOMATION
ETERNA 150
2) TECHNICAL SPECIFICATIONS OF THE ETERNA 150 AUTOMATION
MODEL ETERNA 150D 2 leaves ETERNA 150S 1 leaf
Power supply 230V~ 50Hz +/‑ 10%, 115V~ 60 Hz +/‑ 10%
Max. power 100 W
Stand-by consumption 6W
Maximum weight of leaves Max. 150 Kg/leaf Max. 200 Kg/leaf
Brushless Motor 24Vdc with built‑in encoder
Opening speed Max. 80 cm/s (per leaf)
Closing speed Max. 60 cm/s (per leaf)
Pause time 0 to 30 seconds
Operating temperature ‑15°C ÷ +50°C
Protection class IP22
Sound pressure emission LpA ≤ 70dB (A)
Power supply for external accessories 24 Vdc
Transom dimensions (H x D) 120 x 150 mm
Transom length max 6,500 mm
Frequency of use continuous
