15
10.3) MANUAL RELEASE
RELEASE HANDLE FASTENING
The models Fail Secure ET‑EBSFSE and Bistable ET‑EBSBIS
are equipped with the manual release system ET‑EBSSMA, that
is used to release the electric lock in the case of a power failure.
Therefore it is possible to move the leaves freely.
For fastening on both the right and left side of the automation,
you need to fasten the adjustment register on the bottom of the
release handle.
Insert the steel cable located inside the exible sheath as shown
in the gure.
Fix the bottom of the release knob to the side panel, using the
supplied self-threading screws, on the two holes existing in the
side panel.
A
B
C
