43
P31 Leaf delay during closing
For dual leaf door. Increasing the value increases the starting delay during closing of the Master
automation with respect to the Slave automation, necessary in case of overlapping leaves.
At the minimum value 0%, both leaves start together during closing.
P32 Thrust power
Increasing the value will increase the thrust power of the motor.
S
P33
For NB-LET/SLT spring
automations only
Motor thrust distance at closing end (active only with F38 = OFF)
At the default value 0%, the function is disabled.
Increasing the value increases the degrees from the end of the closing run in which the motor thrust is
enabled to facilitate the completion of the closing manoeuvre, in critical situations caused, for example,
by draughts.
At 100% of the value the motor is enabled throughout the closing phase.
The thrust power of the motor is regulated by the potentiometer P15.
P34
Potentiometer enabled if
function F77 = ON
(see PRIVACY FUNCTION)
It allows to adjust the time within which the user can issue the lock command from the inside once the
door has closed.
If the value is "0", time is innite, therefore the lock command can always be issued from the internal
touch button.
Values ranging between "1" and "100" will set a time ranging between 1 and 100 seconds (factory
setting = 10 seconds).
Once this time has expired, if the electromagnet is not locked, activating the touch button causes the
door to open.
P35
Potentiometer enabled if
function F77 = ON
(see PRIVACY FUNCTION)
It allows to set the time after which the electromagnet is automatically released after the door has been
locked from the inside.
If the value is "0" (factory setting), time is innite, therefore the electromagnet remains locked until the
user activates the inside button to leave.
Values ranging between "1" and "100" will set a time ranging between 1 and 100 minutes.
Once this time has expired the signalling light ashes, alternately switching between red and green, to
warn the user that within 3 minutes the door will be unlocked.
P36 Not used
P37 Not used
P38 Not used
P39 Not used
P40 Not used
P41 Not used
P42 Not used
P43 Slowdown ramp during opening
Increasing the value, leaf slowdown moves toward the last degrees of the opening cycle.
S
P44 Intensity of the braking during opening
Increasing the value increases the leaf braking intensity during the opening cycle.
S
P45 Intensity of the braking during closing
Increasing the value increases the leaf braking intensity during the closing cycle.
S
P46 Not used
P47 Not used
P48 Scheduled maintenance
This potentiometer allows you to select the number of opening/closing cycles after which the message
"SCHEDULED MAINTENANCE" appears on the display of the program selector.
The maintenance signal can also be displayed on the open collector output (terminal 29) or on the OUT2
(terminal M5) of the electronic control unit if the operating mode C is selected in the function F41m.
When set to OFF (default value), the scheduled maintenance message is never displayed.
Select the number of cycles after which maintenance is to be reported according to door operation and
to the usage conditions:
8K (8,000 cycles), 16K (16,000 cycles), 32K (32,000 cycles), 64K (64,000 cycles), 128K (128,000
cycles), 256K (256,000 cycles), 512K (512,000 cycles).
P49 Not used
P50 Not used
