27) EN-RF1 RADIO RECEIVER
1 - GENERAL INFORMATION
The single-channel receiver EN-RF1 is a 433.92 MHz radio receiver designed to open the automatic door NEPTIS PLUS using the
transmitters manufactured by Label.
In Table 1 there is a list of radio transmitters produced by LABELSpa.
2 - DESIGNED USE
The receiver EN-RF1 must be coupled to the connector J12 of the logic card LCB and it is intended to control the opening of the
automatic door in all the work programs of the automation.
WARNING:
The opening command of the automatic door is issued by the radio control, but movement protection and safety are delegated to organs
other than the receiver.
It shall never be used in any case where the door activation or deactivation may cause injuries and damage. Receiver in class 3
according to the standards ETSI EN 300-220-2 V.3.1.1 (2016-11).
3 - INSTALLATION OF THE RECEIVER
Plug the EN-RF1 receiver (g. 1) into the J12 connector of the LCB logic card of the automation (g. 2). Proceed with saving the radio-
controls (g.3) as follows:
a) Enter the programming mode of the transmitters pressing and holding the button SW1 until the LED L1
is steadily lit (approx. 3
seconds).
b) Press the button of the transmitter to be saved. Successful saving will be indicated by 5 fast ashings of the LED L1
.
c) Then LED L1 will turn on steadily again and it will be possible to save another transmitter by repeating the operation described in
point b), and so forth for all the transmitters to be used.
• A maximum of 250 transmitters can be saved on the receiver.
d) Once the transmitter saving procedure is nished, exit the programming mode by pressing and holding the button SW1 until the LED
L1 ( ) turns o.
4 - USE OF THE RADIO CONTROL
By pressing the button of a saved transmitter, the automatic door opens and the LED L1 of the receiver remains on until the button of the
transmitter is released.
The radio control opens the door in all the operating programs of the automation.
5 - RECEIVER MEMORY ERASURE
Should it be necessary to erase all the transmitter codes saved in the memory of the receiver EN-RF1, proceed as follows:
a) Extract the EN-RF1 receiver from the J12 connector of the LCB logic card.
b) Hold the receiver SW1 button pressed and simultaneously insert the EN-RF1 receiver into the J12 connector of the LCB logic card.
c) Release the button SW1 from the receiver EN-RF1 only after the LED L1 of the receiver starts ashing.
Now the LED L1 of EN-RF1 blinks fast
to indicate that the receiver is ready to save the codes of all the transmitters of the LABEL
range, both rolling code models and dip switch models.
If you only wish to save the rolling code transmitters (SPYCO model), excluding all dip switch models, briey push the SW1 button;
the LED L1 blinks slowly to indicate that the receiver is ready to save only the SPYCO transmitter codes.
To switch from one mode to the other, press the button SW1.
d) After selecting the desired mode, press and hold the button SW1 for about 3 seconds until the LED L1
begins blinking very fast
for about 8 seconds, signalling that the receiver memory is being erased.
e) When the memory of the receiver EN-RF1 has been erased, the LED L1 will turn o.
f) Now it is possible to save again the code of the transmitters to be used, following the procedure described in paragraph 3.
6 - TECHNICAL SPECIFICATIONS
Power supply 12Vdc
Power draw 10mA at rest - 50mA in operation
Outputs OPEN COLLECTOR
Frequency 433.92 Mhz
Memory Capacity 250 users
Range without obstacles 30 meters
Operating temperature -20° / +55°
Receiver class (ETSI EN 300-220-1 Chapter 4.1.1) Class 3
7 - DECLARATIONS
Marketing, sale and use are valid without restrictions in all EU countries.
With this document Label SpA declares that the receiver EN-RF1 complies with all the essential requirements and with all other relevant
provisions established by the directive RED 2014/53/EC.
The declaration of conformity is annexed to the instructions of the receiver EN-RF1.
