6
3) NEPTIS PLUS AUTOMATION COMPONENTS
LEGEND:
1 LOGIC CARD LCB
2 PWB ELECTRICAL WIRING AND POWER SUPPLY CARD
3 RE-CLOSURE SPRING (MODELS NB-SLT, NB-LET)
4 SPRING PRELOAD REFERENCE LINE
5 BRUSHLESS GEARMOTOR
6 MOTION TRANSMISSION SHAFT OUTLET
7 INTERNAL WIRING BETWEEN LCB AND PWB CARDS
8 SPRING PRELOAD LOCKING SCREW
9 PLASTIC PLATE
10 SWITCHING POWER SUPPLY
11 NB-BAT MODULE, BATTERY CHARGER CARD
12 WIRING BETWEEN NB-BAT MODULE AND PWB CARD
13 NB-BAT MODULE, BATTERIES
14 BATTERY CABLE CONNECTION
STANDARD AUTOMATION:
AUTOMATION WITH BATTERY:
