CoaDATA 501 – Operators Manual 2.1 Page 43
3.3 Method Parameters
The settings on the analyzer are set by the manufacturer. Before routine
tests can be performed, the user must change certain reagent specific
parameters such as lot number and calibration curve parameter.
The following parameter settings are manufacturer’s settings.
Program Version: V X.xx Release mm.dd.yy
Printer: AUTO
Computer: OFF (only for service purposes!)
Beeper: ON
Secret no.: 11111
Cuvette detection: OFF
Single determination: for all methods
Method Parameters
(factory settings)
Calibration curve P1 - P9
P1 P2 P3 P4 P5 P6 P7 P8 P9 Unit 100% ratio ISI Rea. Lot no.
1 PT Value 100 50 25 10 0,0 0,0 0,0 0,0 0,0 % 11,6 1 1.05 1
Time 11,6 17,7 29,9 66,6 0,0 0,0 0,0 0,0 0,0 sec
2 aPTT Value 0 0 0 0 0 0 0 0 0 27,5 0 1.05 -
time 0 0 0 0 0 0 0 0 0 sec
3 Fib.1 Value 8 4 2 1 0 0 0 0 0 g/l 0 0 0 2
Time 8,5 16,5 32 80 0 0 0 0 0 sec
4 Fib.2 Value 804 402 199 100 0 0 0 0 0 mg/dl 0 0 0 3
Time 8,5 16,5 32 80 0 0 0 0 0 sec
5 Thrmb Value 0 0 0 0 0 0 0 0 0 0 0 0 -
Time 0 0,0 0,0 0,0 0,0 0,0 0,0 0,0 0,0 sec
6 Intr. Value 200 0,5 0 0 0,0 0,0 0,0 0,0 0,0 % 0 0 0 -
Time 5,0 150,0 0,0 0,0 0,0 0,0 0,0 0,0 0,0 sec
7 Extr. Value 200,0 0,5 0,0 0,0 0,0 0,0 0,0 0,0 0,0 % 0 0 0 -
Time 5,0 150,0 0,0 0,0 0,0 0,0 0,0 0,0 0,0 sec
method store
method name
max. 5 characters
incub [sec] (0=off)
start-reagent [µl]
1st conversion reference curve
(quick)
1st conversion unit
decimal place
2nd conversion (INR/RATIO)
min value (conc)
max value (conc)
time (lin / log / rezi)
value (lin / log / rezi)
1 PT 60 100 curve % 1 INR 5 150 lin rezi
2 aPTT 120 50 - 0 Ratio 0 0 lin lin
3 Fib.1 60 100 curve g/l 1 - 0,2 10,0 log log
4 Fib.2 60 100 curve mg/dl 0 - 20 1000 log log
5 Thrmb 60 100 - 1 - 0 0 lin lin
6 Intr. 120 50 curve % 1 - 0,5 200 log log
7 Extr. 60 100 curve % 1 - 0,5 200 log log
