PL1220 Owner’s Manual
59
NOTE
RDWorks must be installed on the PC and the laser machine
must be fully set up and operational.
1. Connect the PC to the laser machine via the USB cable or Ethernet cable.
2. On RDWorks, go to “File” and select vendor settings.
3. Enter the vendor password: RD8888.
4. Select the “User” tab on the right-side control panel (system work plat).
5. Click “Read”.
7.3.1 Verify Settings
Page settings > page size > Page width: 19.685 inch (500mm), Page height: 11.811 inch
(300mm)
NOTE
Reference the RDWorksV8 software manual for software-
related guidance aside from this initial setup.
7.3.2 Troubleshooting
Table 8-4: RDWorks Troubleshooting
Problem(s) Solution(s)
Cannot connect or
communication error
Verify the laser machine is powered on and
functional. Use a hardwired USB to USB connection
if the Ethernet method is problematic.
