PL1220 Owner’s Manual
12
1.7 Electrical Safety
1.7.1 Power Connections
A separate electrical circuit should be used for each machine. The circuit should not be less than
the wiring listed in the table below and should be protected with an appropriate circuit breaker
based on the total running and start-up amperages (listed below). If an extension cord is required,
use only 3-wire extension cords which have 3-prong grounding type plugs and matching
receptacle which will accept the machine plug.
Before connecting the machine to the power source, verify the
switch is in the “OFF” position.
Table 1-2 Power Connections
MLC122040-2
Voltage 110V
Phase 1PH
Hertz 60Hz
Full load amperage 9.6A/14.4A (all components)
The table below lists RECOMMENDATIONS to be used for this machine
based on the information in the above table. Variables outside of our
control are
• Actual voltage supplied to the machine
• Electrical code that must be met in your local province.
An electrician will verify that all the demands are met to properly wire
the machine. If you have absolutely any doubt when wiring this machine,
please consult with a qualified electrician.
Plug/receptacle 5-15
Wiring (gauge) 14 Ga. (minimum)
Circuit breaker 15 AMP
