PL1220 Owner’s Manual
45
6.7 Exhaust Fan
DANGER
DO NOT plug in the PL1220 machine until setup and assembly
is complete.
WARNING
DO NOT connect to a power supply until the setup is
complete. DO NOT perform any of the following steps,
installations, or adjustments with the machine connected to a
power source unless directed to do so.
DO NOT let the fan tip over. The fan can tip over if not
fastened to a base.
Reference the connection diagram in section 2.0 for all
connections to the PL1220.
The machine must be ventilated during operation. Three (3) band clamps, two (2) ducting tubes,
the blower unit, and a flathead screwdriver to fasten the clamps are required.
