PL1220 Owner’s Manual
80
14.0 Specifications
Table 15-1: PL1220 Laser Specifications
PL1220 Laser
Voltage 115V
Hertz 60Hz
Phase 1Ph
Running Amperage 9.6A (14.4A with all components)
Recommended
Breaker
Dedicated 15A on power strip for all components
Table 15-2: CO2 Laser Specifications
CO2 Laser
Laser Tube RECI Water Cooled 40W 15,000H working file
Optics U.S. II-VI Focusing lens & beam combiner
Drive System Leadshine motors & 3PH drivers
Linear Guides Hiwin HG resin capped
Work Envelope 12” x 20”
Table Lift 12”
Control Software RUIDA RDWorks, Lightburn option
Engraving Speed 0-500mm/s
Cutting Speed 0-500mm/s
Laser Output
Control
0-100% Software controlled
Exhaust 300CFM
