PL1220 Owner’s Manual
81
Working
Environment
32º-104ºF, Humidity 5-95%
Table 15-3: PL1220 Dimensions
Dimensions
Net Weight 300 lbs (all components)
Ship Weight 325 lbs
Assembled Height
10” (top unit)
27” (with base)
40” (with base and stand)
Assembled Width 40”
Assembled Depth 30”
Table 15-4: Chiller Specifications
Chiller CW-3000DG
Voltage 115V
Hertz 60Hz
Phase 1Ph
Running
Amperage
0.9A
Net Weight 21 Lbs
Ship Weight 26 Lbs
Tank Capacity 9L (2.3 Gal)
Flow 10L/min (2.64 Gal/min)
