PL1220 Owner’s Manual
71
Table 12-6: Thin Material Cont’d
Leathers
40 WATT 80 WATT 120 WATT
Engrave 150 – 100% 300 – 100% 450 – 100%
Cut 1/8 inch (3.2mm) 75 – 100% 175 – 100% 300 – 100%
Leathers are complicated to process because of the range in
oil density and/or finishes of the leather. It is best to use raw
dried leather to cut or engrave.
Table 12-7: Marked Metals
Cermark®, Alumark®, Thermak®, Painted, Anodized
40 WATT 80 WATT 120 WATT
Engrave - Cermark® 125 – 100% 250 -100% 300 -100%
Engrave – Anodized 450 – 50% 450 -30% 450 – 25%
Engrave – Painted 450 – 40% 450 – 25% 450 – 15%
There are several products that use sintering to make a
ceramic marking into a metal surface These parameters
should only serve as a baseline to achieve a final engraving.
Test a sample piece prior to running a work file.
