Lake Shore Model 340 Temperature Controller User’s Manual
A-8 Curve Tables
Table A-9. Standard DT-670 Diode Curve
Breakpoint V Temp. (K) Breakpoint V Temp. (K) Breakpoint V Temp. (K)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
0.090570
0.110239
0.136555
0.179181
0.265393
0.349522
0.452797
0.513393
0.563128
0.607845
0.648723
0.686936
0.722511
0.755487
0.786992
0.817025
0.844538
0.869583
0.893230
0.914469
0.934356
0.952903
0.970134
0.986073
0.998925
500.0
491.0
479.5
461.5
425.5
390.0
346.0
320.0
298.5
279.0
261.0
244.0
228.0
213.0
198.5
184.5
171.5
159.5
148.0
137.5
127.5
118.0
109.0
100.5
93.5
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
1.01064
1.02125
1.03167
1.04189
1.05192
1.06277
1.07472
1.09110
1.09602
1.10014
1.10393
1.10702
1.10974
1.11204
1.11414
1.11628
1.11853
1.12090
1.12340
1.12589
1.12913
1.13494
1.14495
1.16297
1.17651
87.0
81.0
75.0
69.0
63.0
56.4
49.0
38.7
35.7
33.3
31.2
29.6
28.3
27.3
26.5
25.8
25.2
24.7
24.3
24.0
23.7
23.3
22.8
22.0
21.3
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
1.19475
1.24208
1.26122
1.27811
1.29430
1.31070
1.32727
1.34506
1.36423
1.38361
1.40454
1.42732
1.45206
1.48578
1.53523
1.56684
1.58358
1.59690
1.60756
1.62125
1.62945
1.63516
1.63943
1.64261
1.64430
20.2
17.10
15.90
14.90
14.00
13.15
12.35
11.55
10.75
10.00
9.25
8.50
7.75
6.80
5.46
4.56
4.04
3.58
3.18
2.62
2.26
1.98
1.74
1.53
1.40
