Lamtec LT 2 - Introduction; System Overview

3 Introduction
9
3 Introduction
The LT 2/KS1-DK lambda transmitter is a universal, microprocessor-based measuring
device for the simultaneous measurement of the concentration of O
2
and oxidising gas
constituents (CO/H
2
), referred to as CO equivalent ( COe ), most commonly in the
exhaust gases of combustion systems in the superstoichiometric range ( l >1 ), in
connection with the KS1-DK combination probe.
3.1 System overview
LAMTEC SYSTEM BUS
Combination
probe KS1-DK
O
2
CO/H
2
(,
)
Operation
servicing
to other
LAMTEC
FMS / VMS / ETAMATIC
LT 1 / LT 2
devices
Option:
CANopen
Modbus
Profibus DP
Ethernet
RS 232
Analogue inputs
and outputs
Analogue inputs
and outputs
Recording
Digital inputs
and outputs
Digital inputs
and outputs
Field bus
CAN
Optional modules
Lambda-
Transmitter LT 2
