3 Introduction
12
3.1.2 LT 2 lambda transmitter
In the version for KS1-DK
Two basic versions are available:
LT 2/KS1-DK lambda transmitter in IP65 wall-
mounted housing
• Sheet steel H400 x W300 x D150 mm
• With display and operating unit
• With two analogue outputs 0/4...20mA
Type 657 R 1028
• Optionally with integrated reference air pump
Type 657 R 1060
This increases the housing size to
500 x 300 x 200 mm (HWD)
• Also see section 4.4.1
LT 2/KS1-DK lambda transmitter on mounting
plate
• 350 x 258 x 132 mm (HWD)
• Without display and operating unit
• Type 657 R 1032
• With two analogue outputs 0/4...20mA
• Also see section 4.4.2
In the version for KS1-DK_E
LT 2/KS1-DK-E lambda transmitter in IP65 wall-
mounted housing
• Sheet steel H400 x W300 x D150 mm
• With display and operating unit
• With two analogue outputs 0/4...20mA
Type 657 R 1033
• Can only be connected to KS1-DK-E via PCB
• See separate publication DLT3010
