7 Service and Maintenance
74
31
4
5 6
element pieces description item-no. material
6 1 metal O-ring 650 P 2057 Inconell 600
5 1 metal O-ring 650 P 2058 Inconell 600
4 1 CO/H2 sensor incl. adapter 656 P 2030 ZrO2-ceramic
3 1 filter 650 P 2055 SIKA H 20
2 6 hex-nut 650 P 2066
1.4571
1 6 hexagon socket head screw 650 P 2065 1.4571
3.) Reinstall the KS1-DK combination probe and connect up the gas lines and electric
cables. Don’t forget the seal
4.) Commission the measurement as described in section 6.
CO/H
2
measuring cell repair kit 500 mm 656 R 2060
1000 mm 656 R 2061
1500 mm 656 R 2062
