10 Appendix
Action Switch position
top selector
switch (1)
Switch position
bottom selector switch
(2)
Buttons/Other
Recall correction ranges STATUS MONITORING DISPLAY
AUTOMATIC
SETTING
CLEAR MEMORY
ENTER
Cold start (long reset) STATUS FAULT/Switch 1 OPEN
Warm start (short reset) STATUS FAULT/Switch 1 OPEN and
switch 2 OPEN
Code entry for parameteri-
sation
STATUS AUTOMATIC
MONITORING DISPLAY
Switch 2/3 OPEN
Switch 4 CLOSE
Scan fault history STATUS MONITORING DISPLAY
AUTOMATIC
SETTING
CLEAR MEMORY
Switch 1 OPEN or CLOSE
(not in FAULT mode)
Recall correction input
values
LOAD RATING ENTER
Firing-rate adjustable via
switch 1 (MANUAL OPER-
ATION)
LOAD RATING AUTOMATIC Switch 1 OPEN/CLOSE
Quit MANUAL
OPERATION
LOAD RATING AUTOMATIC operate a switch, channel 2,3
or 4
Firing-rate adjustable via
switch 1 (internal firing-rate
default)
LOAD RATING SETTING Switch 1
OPEN or CLOSE
EG / ES mode is activated LOAD RATING SETTING
CLEAR MEMORY
Switch 3 CLOSE
Fuel/air ratio control engaged
(No ’ES barred’ message)
EG / ES mode is termi-
nated
SETTING
CLEAR MEMORY
Switch on the front panel oper-
ated EG or ES mode
Display is running time
meter/Status counter
SETPOINT MONITORING DISPLAY
AUTOMATIC
ENTER
Store point SETPOINT
ACTUAL VALUE
FEEDBACK
SETTING ENTER
Clear present curve SETPOINT CLEAR MEMORY ENTER
Display of acceptance data
CRCs for all levels Oil/gas
safety times pre-purge time
SETPOINT
FEEDBACK
ENTER
Traverse channels SETPOINT
FEEDBACK
ACTUAL VALUE
FEEDBACK
SETTING Switch 1 - 4
Channel 5 setpoint adjusta-
ble
DISPLAY
CHANNEL 5
SETTING Switch 2
Scanning of serial No. ACTUAL VALUE
FEEDBACK
MONITORING DISPLAY
AUTOMATIC
ENTER
Call up flame intensity ACTUAL VALUE
FEEDBACK
AUTOMATIC Channel 3 up
