Lamtec VMS Series - Configuration Cards (Examples); Processor Card

19
4 Settings
4.2.2 Configuration Cards (Examples)
Fig. 4-2 Example: Configuration card
4.2.3 Processor Card
Fig. 4-3 Processor card
NOTICE
Continuous channels must have all be fitted with additional cards from channel 1 onwards
