137
10 Appendix
Dimensions
Dimensions (H x B x T) [mm] [in.] 147 x 147 x 328 (5.8 x 5.8 x 12.9)
Weight [kg]
Material
Input data
Voltage supply (optional) 230 V +10 % - 15 % 50/60 HZ
To be used only in a grounded power line network!
Power consumption ca. 34 VA
Characteristics
Display 16-character alphanumeric display, switchable to target value,
firing rate value, status, actual value, feedback, target value
feedback, digital inputs, continuous positioning output value,
correction input and correction range.
Running text display.
Inputs (digital/analogue) 16 digital inputs
12 analogue inputs
all none isolated
Digital signal inputs 16 via isolated relay contact (24 VDC), or optionally via 230 V
module,
type 660R0018
Correction inputs 2, adjustable to 0 ... 20 or 4 ... 20 mA
Channel an action parametrically adjustable
Firing rate preset Selectable
– potentiometer 1 - 5 k
– currant signal (0/4 ... 20 mA) or
– three-point-step positioning output
Optional: PT100 direct actuation (when using the firing-rate-
controller)
Analogue inputs Selectable
– potentiometer 1 - 5 k,
– current signal 0/4 ... 20 mA.
Optional: Namur transducer direct actuation, PT100 direct
actuation
Resolution
per analogue input
999 digits, 10 Bit
Positioning outputs 4 or 5, selectable between continuous or three-point-step, in
VMS 5 channel 5 always continuous.
Three-state-step
Recommended run time of the positioning
drivers
30 s ... 60 s
Outputs (digital/analogue) 8 - 16 digital outputs
1 - 5 analogue outputs
all none isolated
Continuous output
firing rate
0 ... 10 V > 5 k
0/4 ... 20 mA < 600
Signal outputs Faults
Ignition point
Open valves / flaps
high fire position
